AC Pro Drive

MODEL DESCRIPTIONS

Toolmaker

BASIC model for general machining
It stores one surface foot rating.

$2195.00 220v 3hp model or $2395.00 3hp 440v model

Programmable

for REPETITIVE OPERATIIONS - 2 & 3 axis
CNC's WITH NO SPINDLE CONTROL

This model can be used in the MANUAL mode like the Toolmaker. In addition, it can store
up to five spindle speeds with their surface foot ratings and will instantly recall these presets.
This model has an additional feature whch allows the operator to override programmed
RPM for fine tuning without changing the programmed cutting tool diameters. In the
AUTOMATIC mode, the controller unit displays spindle RPM and tool diameter as it is recalled.
This enables the operator to associate recommended RPM versus tool diameter for material
being machined.

$2375.00 3hp 220V model or $2590.00 3hp 440V model

Z-Axis

for REPETITIVE OPERATIONS - 2-Axis CNC's - TAPPING
3-Axis WITH BREAKAWAY QUILL

The Z-Axis model contains all of the above features plus the addition of a
linear glass scale. The Z-Axis model is turned on and off by depressing the spindle
speed control knob. This switches the tool diameter display into the digital read out
mode. It allows the operator to use the controller just like a digital read out when
zeroing out and measuring depth.

By turning on the TAP MODE the Z-Axis model can be programmed to reverse
the spindle at a specfic depth for tapping. Programming is accomplished by
rotating the spindle speed control knob to the desired depth. By holding in the
control knob momentarily the tapping depth is stored into memory. The operator
now only needs to turn on the spindle and start tapping.

When the tap reaches the programmed depth the spindle will automatically reverse,
allowing the tap to exit the part. At .100 above the part, the spindle will automatically
reverse back to the original direction. This allows multiple tapping without the
operator having to manually reverse the spindle.

$2795.00 220v 3hp model or $2995.00 440v 3hp model

KITS are available for most milling machines
and also available for
220v 5hp 3-phase, 440v 5hp 3-phase.
Call for PRICING or closest dealer

WTG&S, Inc.

WTG&S, Inc., 307 West Fork Drive, Arlington, Texas 76012 - (817) 460-6221 - fax (817) 274-9581
E-Mail: sales@acprodrive.com Web: www.acprodrive.com

TM

Made in U.S.A.

U.S. Patent 5914881

< < Discounts available to Machine Tool Dealers and Rebuilders > >
